TECHNICAL SPECIFICATION SHEET
- PRODUCT IDENTIFICATION
- Part Number: 20M64K6 (20M64K6-OP)
- Manufacturer: Parker Autoclave Engineers
- Product Type: One-Piece Male-to-Female High Pressure Adapter
- Connection Series: Medium Pressure (MP)
- TECHNICAL SPECIFICATIONS
- Maximum Working Pressure: 20,000 PSI (1,379 bar)
- Male Connection Size: 3/8" Medium Pressure (SF375CX connection type)
- Female Connection Size: 1/4" Medium Pressure (SF250CX connection type)
- Body Material: Cold Worked 316 Stainless Steel
- Operating Temperature: Dependent on seal and application limits
- DESIGN FEATURES
- One-piece compact design eliminates the need for shorter tubing nipples
- High-flow capability with minimum pressure drop
- Robust construction for extreme and hazardous environment safety
- COMPLIANCE & APPLICATIONS
- Industry Applications: Oil and Gas, Chemical, Petrochemical, Research Laboratories
- Mediums: Liquid and gas high-pressure process systems
