General Information
- Manufacturer: Parker Hannifin (Autoclave Engineers Division)
- Product Model: CLX12
- Product Type: Medium Pressure 90° Elbow Fitting
- Connection Type: Cone and Threaded (SF750CX / 3/4" Medium Pressure)
- Components Included: Complete with glands and collars
Pressure & Temperature Ratings
- Maximum Allowable Working Pressure (MAWP): 20,000 PSI (1,379 bar) @ room temperature
- Operating Temperature Range: -423°F to 1,200°F (-252°C to 649°C)
Material Specifications
- Body Material: Cold-worked 316 Stainless Steel
- Gland Material: 316 Stainless Steel or Hardened 17-4 PH Stainless Steel
- Collar Material: 316 Stainless Steel
Physical Dimensions & Sizing
- Tube Outside Diameter (OD): 3/4 inch (19.05 mm)
- Orifice Diameter: 0.516 inch (13.11 mm)
- Block Thickness: 1.38 inch (35.1 mm)
- Center-to-Face Distance (Fitting Side): 1.88 inch (47.8 mm)
Applications
- High-pressure chemical injection systems
- Offshore oil and gas production platforms
- Hydraulic power units (HPUs)
- High-pressure gas and liquid testing rigs
